Overview
Enables remote operation of curtains and link to specified rules & schedules for auto operation.
The Micro Motor Controller is specifically used to enable Z-Wave command and control (up/down) for existing window covering motors. The wireless module is powered from the mains supply and is a three-wire design which requires a neutral connection.
Network Protocol
Features
- Easy and Hassle free Installation
- Repeater Function
- Wireless strength Indicator
- Surge and Overload Protection
- Miniature size fits into any standard gang boxes
Technical Specifications
- Input: 230V 50Hz input
- Output: 575W or 2.5A max output
- Radio frequency: 865.22Mhz (IN)
- Transmitting power: 0 dBm
- Range: 15 meters
- Control function: relay
- Status Indicator: LED
- Operating Temperature: 0-40 Celcius
- Operating Humidity: 95%
- Dimensions: (52x50x27mm) 60g
- Open/Close control via Z-Wave, manual Wall Switch and/or built-in button
- Small form factor that fit in most gang boxes worldwide
- 3-Wire installation
- Available for USA, EU and Australian markets (UL, FCC, CE, C-TICK, ROHS)
- Optimized for Somfy WT Motors
